Multimedia digital conference unit with touch screen
Overview
The VIS-DMD-T is a multimedia conference unit based on the VISSONIC AUDIOLINK
multimedia IP network technology. It is equipped with a 4.3-inch touch screen, which improves the
flexibility of the conference and the interactivity of the meeting content.
This unit can set as chairman, delegate, VIP or dual-user unit according to the requirements of the
conference. As the various requirements of meeting, it can upgrade the software to achieve more
functions without changing unit or hardware.
The current software module contains five functions:
- Vote
- NFC card identification
- Simultaneous interpretation
- Dual user
- Bluetooth
As chairman unit, you can use the touch screen on the VIS-DMD-T unit to manage different aspects of the meeting. It allows you to start, pause meetings, view request-to-speak lists, approve request, view addressor profiles and speaking times, and even record meetings, easily start and stop voting etc.
As delegate unit, you can view the agenda and the remaining time to speak. You can even see who is speaking and the position you are on the request list.
Features
1. Compatible with IEC 60914, GBT 15381-94 standard
2. The unique AUDIO-LINK digital network technology realizes all digital signal transmission
and processing.
3. Single CAT5e cable transmits 64 channels of audio and various information.
6. High-fidelity sound quality, lossless audio transmission technology, 48K audio sampling
frequency, 20Hz ~ 20KHz response frequency.
7. Support the conference controller to output 16-band equalized EQ to achieve sound field
adjustment; pressure limit, which can recognize the noise gate passed by human voice; AGC
automatic volume gain control; AFC automatic feedback suppressor; support auto-mix
technology.
8. 4.3-inch capacitive touch screen and built-in NFC reader for quick identification of participants
9. All-in-one touch screen conference unit can be configured as a chairman unit, delegate unit,
VIP unit or dual delegate unit
10. Can easily expand functions by setting software modules
Functions
1. The design is compact, ergonomic with high-tech features
2. adopt standard CAT5e as the connection cable, which is convenient for standardized
engineering wiring installation and maintenance.
3. All-in-one touch screen, the unit can be set as the chairman, delegate, VIP or dual delegate unit
4. Set as chairman unit, can pause the delegate's speech, close the delegate's speech, view the
speaking request list, approve or reject the delegate's speech request, and functions of starting
conference recording, stopping recording, selecting conference topics, initiating sign-in, and
voting.
5. Set as delegate unit, you can view your position in the request list, information of the addressor,
and view the meeting topic.
6. Set as VIP unit, the system can set up to 32 VIP delegate units.
7. Contains five optional function modules:
- Voting: three-button / two-button voting
- NFC identification: Sign in with NFC card to accurately identify user information.
- Simultaneous interpretation channel: support 2 language channel selectors, each selector
supports 64 languages independent selection.
- Dual users: Supports two participants sharing one unit to achieve camera tracking at two
locations; enabling two delegates to vote on one unit.
- Bluetooth: can be connected to hearing aids etc
8. 4.3-inch capacitive touch screen displays conference information, such as agenda, addressor
information, addressor list and request-to-speak list, speech timing, current time and date,
system language switching, and unit version information.
9. The conference unit has sign-in function and service function through the touch screen
10. Supports set the current microphone sensitivity and 8-band equalizer EQ adjustment.
11. Can be configured with gooseneck microphone or rectangular digital and analog dual backup
microphone
12. Dual headphone interface design, volume can be adjusted through touch screen
13. Hand in hand loop connection and star connection, the system is more reliable. Replacement and failure of one unit will not affect the normal operation of other units in the system.
14. Hot-swap function of conference unit, automatic recovery function.
15. The number of speakers limit function: you can set the speaker units that are turned on at the
same time (the number is 1/2/4/6, and a maximum of 32 units are allowed to speak in the full
open mode)
16.Has the following speaking modes:
"OPEN" open mode, "VOICE" voice control mode, "OVERRIDE" mode, "APPLY" application
mode, "PTT" press and hold to speak (optional), "ALL" full open mode (optional)
17. When used with camera and a camera tracking controller, it has an automatic camera tracking
function.
Control & Indicators
Microphone with two-color LED ring, red indicates speaking status, green indicates request to speak
4.3-inch capacitive touch display.
Microphone switch button
Chairman unit with priority button and approve to speak button
Connection
Pluggable microphone connection base
Two 3.5mm stereo headphone jacks
Two RJ45 connectors
Technical parameter
Screen size :109.22 mm (4.3 inches)
Resolution: 800x480
Screen type: Capacitive multi-touch
Supported contactless NFC cards in following standards: ISO / IEC14443 Type A
Connection method: CAT5 / CAT6 cable + buckle
Electrical parameters
Supply voltage 48V DC
Supply consumption:5 W
Frequency response :20 ~ 20000Hz
THD at rated level <0.1%
Dynamic range> 90 dB
S / N ratio> 90 dB
THD at rated level <0.1%
Audio input
Nominal microphone input 80 dB SPL in accordance with IEC60914
Maximum sound pressure 125dB (THD <3%), in line with IEC60914
Sensitivity -46 dBV / Pa
Audio output
Headphone load 16Ω Headphone volume 10mW
Headphone jack 3.5mm stereo jack Input impedance 2kΩ
Mechanical parameter
Installation desktop installation
Dimensions (height x width x thickness, without microphone)
72 x 259 x 139 mm
Color: Black
Weight 0.7KG
Environmental parameters
Operating temperature 5 ºC to +55 ºCRelative humidity <90%
Item Model for Order:
hardware
VIS-DMD-T ............ Multimedia touch screen conference unit
VIS-DCP2000-D ..... Full Digital Network DSP Conference controller
VIS-MDA .......... Rectangular microphone, Digital + Analog output dual backup microphone
VIS-M220 ........ 220mm microphone (black) with anti-wind foam cover
VIS-M330 ........ 330mm microphone (black) with anti-wind foam cover
VIS-M410 .........410mm microphone (black) with anti-wind foam cover
VIS-M480 ........ 480mm microphone (black) with anti-wind foam cover
VIS-M600 ........ 600mm microphone (black) with anti-wind foam cover
Optional software function module
VIS-LLGE ................... Dual 64-channel selector software module
VIS-LVOTE ................ Vote software module
VIS-LIDEN ................. NFC identification software module
VIS-LDUAL ................ Dual user software module
VIS-HLBLTH .............. Bluetooth Hearing Software Module
In order to fully configure, manage and use the device, CLEACON SYSTEM management software
is required.
Provides the following standard authorizations:
VIS-CLEACON SETUP Conference Basic Setup Software Module
VIS-CLEACON MIC Microphone Control Software Module
VIS-CLEACON VOTE conference voting management software module
VIS-CLEACON INTERP Simultaneous Interpretation Management Software Module
